Ultrasint® PP nat 01
3D printing material

Ultrasint® PP has a lot of valuable properties, boasts excellent plasticity, higher elongation, durability, and low moisture absorption. Its high rigidity makes it especially well-suited for technical applications and durable 3D printed polypropylene parts.

Colors

Characteristics

Surface Look
Details
Strength
Flexibility

Ultrasint® PP nat 01 Material Guide

What is PP nat 01?

Polypropylene or PP is a semi-crystalline thermoplastic polyolefin. This advanced material powder is popular for a wide range of innovative applications. Indeed, Polypropylene is part of standard plastics and is the most used polymer; which is now useable with additive manufacturing!

3D printing PP offers the possibility to make the most of the well-known characteristics of this plastic: excellent chemical resistance, media tightness, and ductility. The rigidity of this PP plastic material makes it really well suited for technical applications and durable 3D printed parts. This white and translucent material has great technical features, especially useful to improve your production process.

This PP nat 01 material is 3D printed using Selective Laser Sintering technology. Please keep in mind that you will have to respect specific design guidelines to avoid any problem during the additive manufacturing process. Be sure to check the material design guidelines while creating your 3D file and before you send it for 3D printing.

What are the possible applications of polypropylene?

Are you looking for a 3D printing material offering strength, ductility and stiffness to manufacture your end-use parts? Our PP 3D printing material printed using SLS technology has a mechanical profile enabling new applications, especially for the automotive industry and the consumer goods market. For example, Polypropylene can be used to 3D print interior components, dashboard parts, airflow, or fluid systems for the automotive sector. PP 3D printing material is perfect for industrial uses, from pipes to machinery.

The formula of PP nat 01 has excellent plasticity, a higher elongation, and low moisture absorption. Tubes, tools, jigs, and fixtures can be easily 3D printed using this PP material.

PP can become an alternative to Nylon PA12 if you want a resistant material, perfectly suited for production!

  • Chemical Resistant
PP SLS

Thanks to its high chemical resistance, it is possible to use it to create reservoirs for nearly all kinds of media and chemicals, or solvent resistant packagings.

  • Strong and Lightweight

PP SLS

Density: 0.890

Manufacturing strong and lightweight is important for various sectors, such as the automotive and consumer goods fields. PP is resistant to strong impacts.

  • Airtight and Watertight

PP SLS

Polypropylene material is perfect to create fluid reservoirs. Using additive manufacturing to create reservoirs or packagings will allow to produce parts with intricate shapes, perfectly adapted to your space constraints.

Pricing​

The printing price of your design is calculated automatically the moment it is uploaded. As you modify your object (changing material, finishing, size, using batch control or hollowing feature, etc.) you will note that the price changes automatically. The pricing is based on a series of factors, including total volume, object size, and bounding box – to name a few.

The estimated shipping time is also calculated automatically as the object is uploaded and each time you make a modification on it. Delivery time should be added to processing time.

For more information, check our pricing page

How does SLS 3D printing technology work?

Sculpteo uses a layer by layer process called Selective Laser Sintering (SLS) to manufacture PP parts.

The Selective Laser Sintering technology uses a highly specific laser that sinters thin layers of powder together one layer at a time. After each round of lasering, the printing bed is lowered and another layer of powder is evenly swept across the top for another round of sintering. This 3D printing process continues until the part is fully printed according to the 3D file.

Maximum size

  260 x 260 x 300mm

The maximum size of your models are limited by the physical size of our 3D printers – nothing can be printed larger than the printer bed.

Due to the printing process, your objects will have upskin and downskin. Upskin is a little concave, whereas downskin will show slight convex. Upskin will appear on the top of your object, downskin at the bottom. This is important to consider when you set the orientation of your 3D model. If the upskin and downskin will affect your design, set the orientation beforehand and we will honor it, if you are not sure, our technicians will choose the best one.

Standard layer thickness120µm
Accuracy± 0.3% (minimum of ± 0.3 mm)

Minimum wall thickness  1mm

Stemmed elements with support1mm
Stemmed elements without support1.2mm

Minimum height and width details

Embossed : 0.7 mm


Engraved : 0.7 mm

Ratio Depth / width

1/1

A detail’s minimum precision is mainly determined by the resolution of our 3D printers. However, during the cleaning process, a fine layer of detail can also be lost. In order for a detail and text to be visible we recommend following our recommended sizes at the very least.It’s possible that particularly fine embossings and engravings will not be visible, as the carving could get filled with excess powder that is later unable to be cleaned out. If an embossing or engraving is an essential part of your design we recommend making them as deep as possible. To ensure a better powder removal (thus a better detail visibility), the width of your details must be at least as big as depth.
Enclosed parts ?Yes
Interlocking parts ?Yes


Our material has the ability to print the most complex designs of our materials . An example of a complex design is a volume enclosed within another volume, like a chain or a ball joint connection. Our printers have the ability to print a fully interlocked chain, with no support structures to remove.

Minimum spacing between fixed walls0.7 mm
Minimum clearance between parts0.7 mm


For a successful 3D print a minimum clearance between objects is required to allow excess material to be sand blown out. If this space is not left within the design, the object will be a solid. This is particularly important for articulated objects – as the space left between the walls will define the object’s ability to move.


Do not forget

Clearance should be at least 0.5 mm, however that is the minimum for small objects. Larger objects require more space between their parts. This is due to the HP printing process. Our printer beds are heated during the process, and larger objects are heated for longer periods. A small space between large objects runs the risk of melting together as it remains under heat for a long period of time. In some other cases, holes should be added to allow us to drain for the excess powder material within the clearance.


Hollowing ?  Yes: 5mm

Our online hollowing optimization tool has the ability to greatly reduce the price and the weight of a print by reducing the amount of material used.

Using the tool requires adding two holes to your model, which will serve as the drain for the excess powder material within the object. The minimum size of these holes is determined by our website. Otherwise, it is possible to hollow your object manually in your 3D modeling software.

Value

Method

Tensile Strength

28 MPa

ISO 527-2

Tensile Modulus

1400 MPa

ISO 527-2

Elongation at Break

30 % (X axis)
10% (Z axis)

ISO 527-2

Charpy Impact unnotched

29 kJ/m²

ISO 179-1

HDT B (0.45 MPa, dry)

102 °C

ISO 75-2
